| Cutting Diameter (DC) | 5/16″ | Flute Helix Angle (FHA) | CW |
| Connection Diameter Machine Side (DCONMS) | 5/16″ | Shank Type | Round |
| Depth of Cut Maximum (APMX) | 3/4″ | End Shape | Corner Radius |
| Overall Length (OAL) | 2-1/2″ | Usable Length (LU) | 3/4″ |
| Cutting Edge Material | Carbide | Corner Radius (RE) | 0.015″ |
| Coating | AlTiN | Grade | KC643M |
| Flute Count (NOF) | 5 | Decimal Equivalent | 0.3125″ |
Product Features
| Remarks | •Kennametal standard dimensions. •Non-center cutting. •Ramping up to 3°. •Unequal flute spacing minimizes chatter for smoother machining. •Single tool for both roughing and finishing operations requiring fewer setups. •Five-flute geometry enables slotting up to 1 x D. | Country of Origin | USA |
Shipping Info
Package Weight
.0926
